Compressors, Domestic Compressor - R134A, Sales Items
Fridge Domestic Compressor R134A 1/5HP
SKU: QD65 / HYS55YCA
Available Stock: Stock is Available
Brand Donper
Full copper windings
1/5 HP
Displacement(cc) 6.5
220-240v
50/60HZ
Watts 168
Universal fridge compressor
R134A
Double door 226- 340 liters
Upright and chest freezer 198-226 liters
Included overload and relay
4 rubber legs
R742.50 incl.VAT
-
Compressors, Domestic Compressor - R134A, Sales Items
Fridge Domestic Compressor R134A 1/5HP
Brand Donper
Full copper windings
1/5 HP
Displacement(cc) 6.5
220-240v
50/60HZ
Watts 168
Universal fridge compressor
R134A
Double door 226- 340 liters
Upright and chest freezer 198-226 liters
Included overload and relay
4 rubber legs
SKU: QD65 / HYS55YCA
R786.60 for 3 item(s)
Fridge Domestic Compressor R134A 1/5HP
High reliability, ultra-high energy efficiency, having wide voltage range and its ability to work in high ambient. can replace a R600A compressor system. LG fridge. Defy fridge . Samsung fridge and KIC fridge. 1/5hp or 1/5 horse power compressor R134a. Hisense fridge compressor 1/5
Always add a new pencil drier and re charge valve with every system.Â
Must pull vacuum on a new installation
Why vacuuming is crucial
Removes Air & Moisture: Prevents acidic corrosion, ice buildup, and refrigerant contamination.
Ensures Efficiency: Air and moisture make the compressor work harder, increasing energy use and shortening its life.
Prevents Failure: Contaminants can lead to premature compressor failure and costly repairs
Fridge compressor 1/5 hp R134A gas
Household refrigerators & freezers.
Beverage coolers & ice makers.
Compact commercial units
| Weight | 9 kg |
|---|---|
| Dimensions | 29 × 19 × 22 cm |
| Power supply | 220/240 V-50 Hz-1 Ph |
|---|---|
| Horsepower | 1/5 hp |
| Displacement | 6,50 cm3 |
| Cooling capacity at ASHRAE LT conditions, R134a | 0,16 kW |
| Refrigerant | R134a |
| Suction pipe | 1/4″ |
| Discharge pipe | 1/4″ |
| Weight | 6,80 kg |
| Rated current | 1,10 A |
| LRA | 12,80 A |
| MCC | 124,00 A |
| Type of oil | Ester |
| Other remarks | Electrical components are included |
| Sound level | 42 dB |
| Application | LBP |
| Technology | Fixed speed |
| Maximum shell bottom temperature | 95 ºC |
| Maximum discharge temperature | 120 ºC |
| Maximum winding temperature | 120 ºC |
| Type of motor cooling | Suction gas |
| Motor type | 1-Ph Induction motor (RSIR) |
| Motor protection type | External |
| Speed | 2920 rpm |
| Vibration | 0,7 m/s2 |
