Allair Low Pressure Control Auto
SKU: P506E
Available Stock: Stock is Available
Pressure controls
Model:P506E
Range:-0.5～5bar
Diff:0.6～4bar
ng></td>-13 °
</table><td>17 bar</tr><strong>Oilfree applications
| Amb. Temp. Note | 80 °C/176 °F for max 120 min | |||
| Ambient temperature range [°C] [max] | 65 °C | |||
| =”attrib”>Ambient temperature range [°C] [min]</strong> | -25 °C | |||
| Ambient temperature range [°F] [Max] | 149 °F | Ambient temperature range [°F] [Min]</stro | ||
| Lubricants compatibility | ||||
| “attrib”>Max. test pressure [bar] Pe | 20 bar | |||
| Max. test pressure [psig] | 290 psig | Max. Working Pressure [bar] | Max. Working Pressure [psig] | 245 psig |
<p><table class=”table table-striped” width=”564″>
Pressure connection size1/4Pressure connection standardDIN 8906Pressure connection typeFlarePressure Male/FemaleMale
R462.00 incl.VAT
Allair Low Pressure Control Auto
Low-pressure switches, on the other hand, are designed to protect your AC unit from low pressures. The switch will shut off the AC unit if the pressure gets too low.
Low-pressure controls can be used to. Directly control a case’s temperature by cycling a compressor on and off. At the required coil temperatures; on medium-temperature equipment, this will also provide a means of defrosting the evaporator; Cycle a compressor on and off when used on a pump down system.
Compressor Protection. Shuts off the compressor if refrigerant levels drop too low, preventing catastrophic failure from running without proper lubrication or pressure.
Temperature Control. Cycles the compressor to maintain specific coil temperatures, essential for cooling and sometimes initiating defrost cycles.
Automatic Pump-Down: In systems with a liquid line solenoid, it stops the compressor when the solenoid closes (e.g., thermostat satisfied), pumping refrigerant to the high side and preventing liquid floodback.
| Weight | 0.2 kg |
|---|---|
| Dimensions | 10 × 10 × 6 cm |
