Fridge/Cold room accessories, Pressure Switches - Danfoss
Danfoss High Pressure Control Manual
SKU: KP5 (060-117366)
Available Stock: Stock is Available
| Amb. Temp. Note | 80 °C/176 °F for max 120 min |
| Ambient temperature range [°C] [max] | 65 °C |
| Ambient temperature range [°C] [min] | -40 °C |
| Ambient temperature range [°F] [max] | 149 °F |
| Ambient temperature range [°F] [min] | -40 °F |
| Max. Working Pressure [bar] | 35 bar |
| Max. Working Pressure [psig] | 510 psig |
| Pressure connection size | 1/4 |
| Pressure connection standard | DIN 8906 |
| Pressure connection type | Flare |
| Pressure Male/Female | Male |
R952.20 incl.VAT
Danfoss High Pressure Control Manual
Use a screwdriver to turn the pressure adjustment spindle. Clockwise increases the pressure, and counter-clockwise decreases it.
Adjust differential: Turn the differential spindle to set the difference between cut-in and cut-out pressures. Clockwise typically decreases the differential, and counter-clockwise increases it.
Model:KP5(060-117366)
Danfoss High Pressure Control
MANUAL
8-32 Bar
| Weight | 0.2 kg |
|---|---|
| Dimensions | 10 × 10 × 6 cm |
